Detection mode
|
MEAN/Ture RMS (switch)
|
DC V
|
50.000/500.00/2400.0mV/5.0000/50.000/500.00/1000.0V
(Input impedance: Approx. 100MΩ [50/500/2400mV], 10MΩ [5/50/500/1000V])
±0.02%rdg±2dgt (Basic accuracy)
|
AC V [Ture RMS]
|
50.000/500.00mV/5.0000/50.000/500.00/1000.0V
(Input impedance: 11MΩ<50pF [50/500mV/5V], 10MΩ<50pF [50/500/1000V])
±0.4%rdg±30dgt (Basic accuracy)
|
AC V [MEAN]
|
50.000/500.00mV/ 5.0000/50.000/500.00/1000.0V
(Input impedance:11MΩ<50pF [50/500mV/5V],10MΩ<50pF [50/500/1000V])
±1%rdg±30dgt (Basic accuracy)
|
DCV+ACV
|
5.0000/50.000/500.00/1000.0V
(Input impedance: 11MΩ<50pF [5V], 10MΩ<50pF [50/500/1000V])
±0.5%rdg±10dgt (Basic accuracy)
|
DC A
|
500.00/5000.0µA/50.000/500.00mA/5.0000/10.000A
±0.2%rdg±5dgt (Basic accuracy)
|
AC A [Ture RMS]
|
500.00/5000.0µA/50.000/500.00mA/5.0000/10.000A
±0.75%rdg±20dgt (Basic accuracy)
|
AC A [MEAN]
|
500.00/5000.0µA/50.000/500.00mA/ 5.0000/10.000A
±1.5%rdg±20dgt (Basic accuracy)
|
DCA+ACA
|
500.00/5000.0µA/50.000/500.00mA/5.0000/10.000A
±1%rdg±10dgt (Basic accuracy)
|
Ω
|
500.00Ω/5.0000/50.000/500.00kΩ/5.0000/50.000MΩ
±0.05%rdg±2dgt (Basic accuracy)
|
LowPower-Ω
|
5.000/50.00/500.0kΩ/5.000MΩ
±0.2%rdg±3dgt (Basic accuracy)
|
Continuity buzzer
|
500.0Ω
(The buzzer turns on at resistances lower than 100±50Ω)
|
Diode test
|
2.4000V
±1%rdg±2dgt
Open curcuit voltage: <5V (Approx. 0.5mA Measuring Current)
|
Capacitance
|
5.000/50.00/500.0nF/5.000/50.00/500.0µF/5.000/50.00mF
±1%rdg±5dgt (Basic accuracy)
|
Frequency
|
2.000 to 9.999/9.00 to 99.99/90.0 to 999.9Hz/0.900 to 9.999/9.00 to 99.99kHz
±0.02%rdg±1dgt (Basic accuracy)
|
DUTY
|
10 to 90%
±1%rdg
|
Temperature
|
-200 to 1372ºC
±1%rdg±1.5ºC
-328 to 2501.6ºF
±1%rdg±2.0ºF (with the use of K-type Temperature probe)
|
Measurement functions
|
DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
Capacitor, Duty cycle ratio, Decibel (dBV, dBm), Continuity Check, Diode Test, LowPower-Ω
|
Other functions
|
Data Hold (D/H), Auto Hold (A/H), Peak Hold (P/H), Range Hold (R/H), Maximum value (MAX), Minimum value (MIN)
Average value (AVG), Zero Adjustment (Capacitor, Resistance), Relative values, Save to Memory, LCD backlight
|
Applicable standards
|
IEC 61010-1 CAT IV 600V / CAT III 1000V Pollution degree 2
IEC 61010-031, IEC 61326-1 (EMC)
|
Power source
|
R6 (1.5V)×4
(Auto power off: approx. 20 minutes)
|
Dimension
|
192(L)×90(W)×49(D) mm
|
Weight
|
Approx. 570g (including batteries and blank cover)
|
Accessories
|
7220A (Test leads)
8926 (Fuse [440mA/1000V])×1 (included)
8927 (Fuse [10A/1000V])×1 (included)
R6×4
Instruction manual
Blank cover
|
Optional accessories
|
7234 (Alligator clip)
8241 (USB Communication set)
8115 (AC/DC Clamp Sensor)
8121 (Load current Clamp Sensor)
8122 (Load current Clamp Sensor)
8123 (Load current Clamp Sensor)
8146 (Leakage & Load current Clamp Sensor)
8147 (Leakage & Load current Clamp Sensor)
8148 (Leakage & Load current Clamp Sensor)
7146 (Banana Ø4 adjuster plug)
8405 (Temperature probe)
8406 (Temperature probe)
8407 (Temperature probe)
8408 (Temperature probe)
9154 (Carring case)
|
