DC V
|
600.0mV/6.000/60.00/600.0V
(Input impedance: Approx. 10MΩ)
±1.0%rdg±3dgt
|
AC V
|
6.000/60.00/600.0V
(Input impedance: Approx. 10MΩ)
±1.5%rdg±5dgt (45 to 400Hz)
|
DC A
|
60.00/120.0A
±2.0%rdg±8dgt (60A)
±2.0%rdg±5dgt (120A)
|
AC A
|
60.00/120.0A
±2.0%rdg±5dgt (45 to 65Hz)
|
Ω
|
600.0Ω/6.000/60.00/600.0kΩ/6.000/60.00MΩ
±1.0%rdg±5dgt (600Ω/6/60/600kΩ)
±2.0%rdg±5dgt (6MΩ)
±3.0%rdg±5dgt (60MΩ)
|
Continuity buzzer
|
Buzzer sounds below 35±25Ω
|
Diode test
|
2.000V
±3.0%rdg±5dgt
Open circuit voltage: Approx. 2.7V
|
Capacitance
|
400.0nF/4.000/40.00µF
±2.5%rdg±10dgt
|
Frequency
|
(AC A) 99.99/400.0Hz
±0.2%rdg±2dgt (100Hz)
±0.1%rdg±1dgt (400Hz)
(AC V) 99.99/999.9Hz/9.999/99.99/300.0kHz
±0.2%rdg±2dgt (100Hz)
±0.1%rdg±1dgt (1000Hz/10/100/300.0kHz)
(Input sensitivity Current: more than 6A Voltage: more than 6V [to 10kHz]/more than 20V [10 to 300kHz])
|
Conductor size
|
Ø12mm max.
|
Applicable standards
|
IEC 61010-1 CAT III 300V, CAT II 600V Pollution degree 2
IEC 61010-031, IEC 61010-2-032, IEC 61326-1, EN 50581(RoHS)
|
Power source
|
R03 (AAA)(1.5V) × 2
* Continuous measuring time: DCV: approx. 150hours, ACA: Approx. 25hours (Auto power save: Approx. 15 minutes)
|
Dimension
|
128 (L) × 92 (W) × 27 (D) mm
|
Weight
|
Approx. 220g (including batteries)
|
Accessories
|
R03 (AAA) × 2
Instruction manual
|
Optional accessories
|
9107 (Soft case)
|
