| Insulation Resistance |
| Test voltage |
2500V |
| Measuring ranges |
2/100GΩ (Auto-ranging) |
| Accuracy |
0.1 to 50GΩ: ±5%rdg
0 to 0.1GΩ, 50GΩ to ∞:±10%rdg or 0.5% of scale length |
| General |
| Applicable standards |
IEC 61010-1, IEC 61010-2-030 CAT Ⅳ 300V / CAT Ⅲ 600V Pollution degree 2
IEC 61010-2-034, IEC 61010-031, IEC 61326-1, 2-2 |
| Power source |
DC12V : LR14/R14 × 8pcs |
| Dimension |
177 (L) × 226 (W) × 100 (D) mm
300 (L) × 315 (W) × 125 (D) mm (Hard case) |
| Weight |
Approx. 1.6kg |
| Accessories |
7165A (Line probe)
7264 (Earth cord)
7265 (Guard cord)
8019 (Hook type prod)
9182 (Carrying case[Hard])
LR14 (Alkaline battery size C) × 8
Instruction manual |
| Optional accessories |
7168A (Line probe with aligator clip)
7253 (Longer line probe with alligator clip)
8324 (Adapter for recorder) |
