| DC V |
0.3V (16.7kΩ/V)
±3% of FS
3/12/30/120/300/600V (20kΩ/V)
±3% of FS |
| AC V |
12V (9kΩ/V)
±4% of FS
30/120/300/600V (9kΩ/V)
±3% of FS |
| DC A |
60µA/30/300mA
±3% of FS |
| Ω |
3/30/300kΩ
±3% of scale length |
| Continuity buzzer |
Buzzer sounds below 100Ω |
| Battery test |
1.5V (0.7 to 2V) ±3% of FS (10Ω load) |
| Temperature |
Possible with the temperature probe 7060 (discontinued). |
| LED |
Approx. 10mA at 0Ω (at 3V of battery voltage) |
| Applicable standards |
IEC 61010-1 CAT III 300V / CAT II 600V Pollution Degree 2
IEC 61010-2-031 |
| Power source |
R6 (AA) (1.5V) × 2 |
| Dimension |
140(L) × 94(W) × 39(D) mm |
| Weight |
Approx. 280g |
| Accessories |
7066A (Test leads)
8923 (Fuse[0.5A/600V]) × 1 (included), 1 (spare)
9103 (Carrying case)
R6 (AA) × 2
Instruction Manual |
