UNI-T UT305C+ SERIES INFRARED THERMOMETERS

UNI-T UT305+ Series Infrared Thermometers

These infrared thermometers are engineered for high-precision, non-contact temperature measurement in industrial, HVAC, and environmental monitoring applications. Designed for versatility, these thermometers offer multiple modes, large data storage, and professional-grade accuracy, making them ideal for technicians and engineers.

  • Delivers a professional infrared measurement mode, allowing accurate surface temperature readings without direct contact.

  • Also features a surface heat conduction detection mode, making it easier to assess heat transfer efficiency on different materials.

  • In addition, provides a surface dew point detection mode, which helps identify areas at risk of condensation.

  • Offers a surface temperature comparison mode, enabling quick detection of hot or cold spots.

  • Equipped with a high-resolution TFT color LCD, ensuring sharp, easy-to-read measurement data.

  • Moreover, includes a trigger lock function and reservation measurement mode, allowing hands-free or scheduled testing for convenience.

  • Stores up to 999 groups of measurement data and supports export in PDF and CSV formats for easy reporting and record-keeping.

  • Displays ambient temperature, relative humidity, dew point temperature, and wet bulb temperature with high accuracy.

  • Finally, supports Type K thermocouple temperature measurement, adding the flexibility of direct-contact testing.

Specifications of UNI-T UT305+ Series Infrared Thermometers

Specifications UT305A+ UT305C+

Measurement range

Infrared temperature measurement -50°C~1850°C

(-58.0℉~3362℉)

-50°C~2200°C

(-58.0℉~3992℉)

The environment temperature measurement -10°C~50°C (14℉~122℉)
Relative humidity 10%RH~90%RH
Type K thermocouple -50°C~1370°C (-58.0℉~2498℉)

Accuracy

Infrared temperature measurement -50°C~0°C, ±(1.0℃+0.1℃/℃)

-58℉~32℉, ±(2.0℉+0.1℉/℉)

0°C~2200°C, ±1.0℃ or ±0.01×t℃ (Which is greater)
32℉~3992℉, ±2.0℉ or ±0.01×t℉ (Which is greater)

The environment temperature measurement -10°C~0°C (14℉~32℉), ±1.0°C (±2.0℉)                                     0°C~40°C (32℉~104℉), ±0.5℃ (±1.0℉)

40°C~50°C (104℉~122℉), ±1.0℃ (±2.0℉ )

Relative humidity ±5%RH
Type K thermocouple ±(0.005×t+1.5)℃, ±(0.005×t+3.0)℉

Certification

 CE UKCA

Diastance ratio(D:S)

55:1

Emissivity

0.1~1.0 (adjustable)

Spectral response

8µm~14µm

Repeatability of infrared temperature measurement

±0.005×t℃(℉)or 1℃(2℉) (Which is greater)

Display resolution

0.1℃(0.1℉)

Unit conversion

℃ / ℉

Laser point

Single laser, output < 1 mW, class II

Data storage

999 groups

Data output format

PDF、CSV

Data communication or charging interface

Type-C USB

Battery

Li-ion 3.7V 2600mAh 18650 rechargeable lithium-ion battery

Charging time

No more than 3 hours

Continuous working time

Work continuously for no less than 20 hours on full charge

Buzzer alarm

Trigger lock function and reservation measurement

Real time, date

LCD type

2.4 inch TFT LCD 320 * 240 pixels

 temperature coefficient

±0.1℃/℃ or ±0.1%℃/℃, ±0.1℉/℉ or ±0.1%℉/℉(Which is greater)

Work at an altitude of

No more than 2000 meters

Drop test

1m

Standard k-type thermocouple probe (bead type)

Measurement range

-40°C to 260°C (-40°F to 500°F)

Accuracy

0.075× T (t is measured temperature)

Lenth

1 m (40 in) long K type thermocouple cable with standard micro thermocouple connector and bead probe

General Characteristics

Power

Li-ion 3.7V 2600mAh 18650 rechargeable lithium-ion battery

LCD screen size

37mm x 49mm

Product color

red and gray

Net weight

375 g

Product size

205 x 65 x 124 mm

Standard accessories

Type-C data cable, Type K thermocouple probe (bead Type)

Standard packing

Gift box, tool box, instruction manual, warranty card

Standard packing quantity

1 pc

Standard packing size

365*160*300 mm
