UNI-TREND UT673PV Solar MPPT Meter
Specifications of UNI-TREND UT673PV Solar MPPT Meter
| Specification | ||
| Max power measurement | 5～800W | ±(1.0%＋10) |
| Max power current(DC) | 0～35A | ±(1.5%＋5) |
| Max power voltage(DC) | 12～60V | ±(1.5%＋5) |
| Open circuit current(DC) | 12～60V | ±(1.5%＋5) |
| Short circuit current(DC) | 0～35A | ±(1.5%＋5) |
| General Features | ||
| Display | Large LCD (52 * 66mm) | |
| Reverse polarity connect Protection |
√ | |
| Over voltage protection | √ | |
| Over current protection | √ | |
| Over temperature protection | √ | |
| Over power protection | √ | |
| Manual/Auto MPPT test | √ | |
| Data hold | √ | |
| Power supply | No battery needed, powered by solar panel | |
| Ovecategory | CAT 0 60V | |
| Certificate | CE, cETLus, RoHS | |
